- Product Line: Controls and Thermostats –Wi Fi
- Wi-Fi® Remote Access: Available
- Humidity Control: Not Available
- Zoning: Zoning Panel Compatible
- Home Automation Compatible: Available
- Hybrid Heat® Compatible: Available
- Proposition 65 Product Warnings: 343824-2 Lead and Lead Compounds
- Evolution System Compatible: Not Compatible
- ENERGY STAR® Certified: Yes
- Smart Home Compatible: Apple HomeKit +more integration
- Remote Sensors: Compatible with SmartSensor
- Alex® Built-in: No
- Voice Control: No
- Initial Cost: $$
- Stream Music: No
- Hands-free Calling: No
Features
- Save up to 23% on heating and cooling costs.1
- Use Amazon Alexa voice commands to change temperature settings, check the weather, hear the news, make a phone call, play music and more.
- Hands-free calling- Call friends and family anywhere in North America free of charge from your thermostat using Amazon Alexa.
- Stream music - Play music through a Bluetooth speaker using Spotify® Connect.2
- Control from anywhere with your iOS® or Android® devices.2
- Compatible with your smart home. Works seamlessly with third-party smart home
- platforms such as Apple® HomeKit®, Amazon® Alexa®, Google® Assistant, Samsung® SmartThings® and IFTTT®.2
- Comfort Schedules: Set schedules to enjoy comfort while you are home, and assist with energy savings while you are away.
- Smart Recovery: Using current weather conditions and scheduled temperature settings, the ecobee thermostats learn the best way to bring the home to its scheduled temperature.
- Five-year limited warranty when purchased through and installed by a Carrier dealer3
OPTIONAL FEATURES
- Can be paired with additional SmartSensors(sold separately) around your home for greater occupancy monitoring and room-specific temperature adjustments.
- Additional energy savings with eco+. Optional software feature, works in the background to help with additional energy savings and efficiency.
1
Compared to a hold of 72°F. See
https://www.ecobee.com/savings/
for details.
2
When connected to the Internet through a Wi-Fi
®
network.
3
See warranty certificate for complete details and restrictions.
Specifications
EFFICIENCY MANAGEMENT
Energy Star®
Energy Star Certified
Smart Recovery
Intelligently adapts beyond manual programming for greater efficiency, while still meeting your ideal comfort levels
Programmability
Create weekly schedule and includes vacation mode
Hybrid Heat® system capable
Allows Bryant
®
gas furnace/heat pump system combinations for best heating efficiencies
CONVENIENCES
Remote access
Use free Apple
®
and Android™ apps for smartphone, a tablet or computer to control and program the thermostat from anywhere
COMPATIBILITY
Conventional (2H/2C)—Gas, oil, electric.
Air-Cooled & Geo-Thermal Heat pumps (2 stage heat pump + 2 stage aux heat/2 cool) (4H/2C).
Dual-Fuel support.
Boiler (2-stage-heating).
DISPLAY
3.5" full-color touch screen
320 x 480 pixel display
POWERING METHODS
Wired 24VAC through terminals C and Rc.
Power Extender Kit enables you to reliably power your thermostat without having to run a fifth wire
PRODUCT DIMENSIONS
Thermostat
Height: 102.9 mm (4 in.)
Width: 102.9 mm (4 in.)
Depth: 21.4 mm (0.85 in.)
Trim Plate
Height: 170 mm (6.7 in.)
Width: 170 mm (6.7 in.)
Depth: 6.25 mm (0.25 in.)
Bryant reserves the right to discontinue or change any specification or design without prior notice or obligation.
1. Your Bryant dealer can help you determine system compatibility regardless of your current brand of HVAC products
